Electrically conductive wheel with pin hole (3 models)
Code: 2470DYK050P30-11
Electrically conductive swivel wheel with ø 50 mm, suitable according to ESD, fork made of pressed steel, galvanized, double ball bearing in the swivel head of the wheel, hole for the pin. Wheel full description and parameters
Product description
Electrically conductive wheel ø 50 mm with pin hole 2470DYK050P30-11
Electrically conductive swivel wheel with ø 50 mm, suitable according to ESD, fork made of pressed steel, galvanized, double ball bearing in the swivel head of the wheel, hole for the pin. Wheel center made of steel extrusion, black rubber non-blackening rim tread, lint-free cover, taper bearing. It can be mounted with standard screws of any length.
- wheel center made of pressed steel
- tread from black rubber non-blackening hoop
- tapered bearing
- temperature resistance -20 °C to 85 °C
- diameter of central hole 11 mm
- turning radius 49 mm
- dynamic load capacity 40 kg
- static load capacity 80 kg
- wheel diameter 50 mm
- tread width 19 mm
- tread hardness Shore A80
- meets the EN 12530 standard
- building height 69 mm
Technical parameters
Carrying capacity
40 kg
Wheel diameter
50 mm
Warranty (years)
7
Manufacturer
All models
Technical parameters
Code
Wheel diameter
Carrying capacity
In stock
Price
