Conjunction outer 2632
Code: 2632-01
Conjunction 2632 is used to connect individual parts (Frames) into assemblies. The external coupling is used to connect the Frames in the vertical direction at the edges of the assemblies. Use full description and parameters
Product description
Conjunction outer 2632
Conjunction 2632 is used to connect individual parts (Frames) into assemblies. The external coupling is used to connect the Frames in the vertical direction at the edges of the assemblies. Use internal 2631 coupling inside assemblies.
- You can recognize the correct connection of the Frames by the click of the connectors
- WARNING: Snapped conjunction cannot be removed without breaking them. During assembly, therefore, check carefully whether the conjunctions are guided in all places into the respective grooves of the Frames
Technical parameters
Dimension D
86 mm
Dimension S
15 mm
Dimension V
4 mm
Warranty (years)
2
Manufacturer
